Stainless Steel Channels

Home > Stainless Steel Channels

Stainless Steel Channel Manufacturer in Rayong, SS Channel in Pattaya, Stainless Steel Channel Supplier in Chonburi, Stainless Steel U Channel Supplier in Nonthaburi, SS Channel Exporter in Chiang Mai, Stainless Steel C Channel in Rayong, Stainless Steel Channel in Bangkok, Thailand

Chanchai Stainless is a leading manufacturer and supplier based in Bangkok, Thailand, offering premium-quality stainless steel channels for structural, architectural, and industrial applications. Renowned for their precision, durability, and adherence to international standards, Chanchai’s stainless steel channels are available in a variety of grades, sizes, and finishes to meet diverse project requirements. These U-shaped or C-shaped profiles are designed for structural support, framing, and reinforcement. With sophisticated manufacturing facilities and rigorous quality control, Chanchai Stainless provides consistent and corrosion-resistant stainless steel channels to customers in Thailand and overseas markets.

Buy Stainless Steel Channels in Nonthaburi, Stainless Steel U Channel Supplier in Chiang Mai, Stainless Steel C Channel in Rayong, Stainless Steel Channel in Rayong, Get the Best Price from SS Channel Manufacturers and Stockist in AL Ain, Check SS Channel Price Per kg in Bangkok, Thailand.

Stainless steel channels are usually made from grades of 304, 304L, 316, and 316L. These materials have chromium (18–20%) and nickel (8–12%), and they provide excellent corrosion resistance, with 316 grades having molybdenum as well for better performance in marine or chemical atmospheres. Mechanical properties are tensile strength in the range of 515–620 MPa and yield strength of about 205–310 MPa. Stainless steel channels are good weldability, machinability, and strength and are hence applicable for load-bearing operations under stressful environments. They are well suited for both structural use for function and decoration due to their durability and good appearance finish.

Stainless Steel Channels Specifications

Standard	ASTM A276, ASTM A479 / ASME SA276, ASME SA479
Condition	HRAP
Size Range	Base: 80 to 150 mm Side: 40 to 75 mm
Thickness	5 to 6 mm (depending on size)
Grades	304, 316
Processing	Bar cutting

Stainless Steel Channels Chemical Composition

Grade	C	Mn	Si	P	S	Cr	Mo	Ni
SS 304	0.08 max	2 max	0.75 max	0.045 max	0.030 max	18 – 20	–	8 – 11
SS 304L	0.035 max	2.0 max	1.0 max	0.045 max	0.03 max	18 – 20	–	8 – 13
SS 316	0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	16.00 – 18.00	2.00 – 3.00	11.00 – 14.00
SS 316L	0.035 max	2.0 max	1.0 max	0.045 max	1.0 max	16.00 – 18.00	16.00 – 18.00	10.00 – 14.00

Stainless Steel Channels Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.0 g/cm3	1400 °C (2550 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Why Choose Stainless Steel Channels From Chanchai Stainless?

Largest Inventory

Customer Support

On Time Deliveries

ISO Certified

Types of Stainless Steel Channels

Chanchai Stainless supplies high-quality materials with a focus on strict testing procedures. All our products go through rigorous testing like hardness testing, chemical analysis through spectro analysis, PMI testing, tensile testing, micro and macro structural tests, pitting resistance, and IGC testing. We assure you of superior performances by these thorough checks. With our quality commitment, we also give all the commercial invoices, packing lists with net and gross weights, box numbers, labels, and a Certificate of Origin legalized or attested by the Chamber of Commerce or Embassy. Third-Party Inspection Certificate will also ensure that the customers are satisfied with our SS Channel’s pricing and delivery.

Frequently Asked Questions

How Do I Choose The Right Stainless Steel Channels?

Choose stainless steel channels based on your project’s required strength, corrosion resistance, and environmental conditions. Consider factors like size, grade, and finish to ensure compatibility with your application.

Can Stainless Steel Channels Be Used At High Temperatures?

Yes, stainless steel channels can be used at high temperatures, particularly grades like 310 and 321, which offer excellent heat resistance. However, their performance depends on the specific alloy and temperature conditions.

What Is The Pressure Rating Of Stainless Steel Channels?

The pressure rating of stainless steel channels depends on their dimensions, grade, and the specific application. It is typically calculated based on factors like wall thickness and material strength, with common grades like 304 and 316 offering high pressure resistance.

Can I Order Stainless Steel Channels In Custom Sizes And Polishes?

Yes, we provide stainless steel channels in custom sizes and polishes based on your specifications. For more details mail us on sales@chanchaistainless.com

SS Channel Price in Chiang Mai, Stainless Steel Channels Exporter in Rayong, Stainless Steel C Channels Dealer In Nonthaburi, Stainless Steel U Channels Manufacturer in Pattaya, SS Strut C Channel Dealer in Chonburi, SS U Shaped Channel Stockist in Rayong, SS Double C Type Channel Suppliers in Bangkok, Thailand.

Stainless Steel Channels Uses

Stainless steel channels are commonly applied in high-strength applications, corrosion resistance, and structural support in various industries. In building construction, they are applied for building frames, supports, and brackets in structures, bridges, and infrastructure works. In the offshore and marine industries, they are well suited for structural parts that are directly exposed to saltwater and severe conditions. They are also applied in food processing and pharma industries for sanitary and easy-to-clean structures. Also, stainless steel channels are utilized in machinery, transportation, and building design for their attractive appearance, durability, and resistance to wear, corrosion, and chemical exposure.
